Our adjustable foot has a decorative round felted base. It is also available without felt, please visit LKF.

Material: LDPE - ZCS - FELT
Standard colors: Black / RAL colors manufactured
UL94:
IP:
RoHS:
Measures expressed in: Millimeters
Drawing PDF:


Reference
Metric Thread (M)
L
H
D
Usable Thread
d
h
Felt

PDF
3D IGS
Add
00301200406 M8 20,00 8,00 34,00 16,00 27,50 2,30
00301200407 M8 30,00 8,00 34,00 26,00 27,50 2,30
00301200408 M8 40,00 8,00 34,00 36,00 27,50 2,30
00301200409 M8 50,00 8,00 34,00 46,00 27,50 2,30
00301200410 M10 20,00 8,00 34,00 16,00 27,50 2,30
00301200411 M10 30,00 8,00 34,00 24,00 27,50 2,30
00301200412 M10 40,00 8,00 34,00 36,00 27,50 2,30
00301200413 M10 50,00 8,00 34,00 45,00 27,50 2,30

If you are interested in our family LKFF, you may be interested in these families as well:

Our threaded insert is manufactured in Zamak alloy for rectangular tubes. It is also available for round tubes: LJMR, square tubes: LJM and for oval tubes: LJMO.   Our square reinforced tube insert has an hexagonal nut which is inserted during the injection process. The tube insert has an excellent finishing and a good resistance. It is suitable for our adjustable feet, please see our Adjustable feet section.   Our round threaded tube insert is a reinforced insert, thus it has been designed for heavy duty applications. Also, the thread is in metal.   Our threaded tube insert is manufactured in ZCS. It is also available for rectangular tubes, please visit our family LJMSZ.     Our ribbed insert for rectangular tubes has a metal nut inserted during the injection process. It is also available for square tubes: LJ, round tubes LJRL, and triangle tubes: LJZZ. It is suitable with our adjustable feet group.   Our trimming cover for round tubes is ideal for protecting adjustable feet, or in order to hide the end of a round tube to get a better finishing look. We recommend its use with the adjustable feet of our range.   Our trimming cover for round tubes is ideal for protecting adjustable feet, or in order to hide the end of a round tube to get a better finishing look. We recommend its use with the adjustable feet of our range.
