The ribbed threaded inserts LJ for square tubes are offered in different designs and sizes. The metric nut, which is incorporated during the injection process, offers a strong fixation. The combination of the available sizes and materials (LDPE and PA6) will offer different properties, such as resistance to weight (we recommend carrying out tests through a sample order).
 RAL colors manufactured

Drawing PDF:
UL94:
IP:
RoHS:
Measures expressed in: Millimeters

LJ
LJ

Reference
For Tube
Tube Thickness
Metric Thread
h
D
H
d / d1
L



More
Info.
00300400318 20 x 20 1,50 to 2,00 M8 4,00 20,50 6,00 14,70 / 19,00 14,20
00300400428 20 x 20 1,50 to 2,00 M8 25,00 20,20 6,80 15,00 / 19,00 30,50
00300400434 20 x 20 1,50 M8 4,50 20,20 6,20 15,00 / 19,00 30,50
00300400319 25 x 25 1,50 to 2,00 M8 4,00 25,80 7,00 19,10 / 22,50 13,60
00300400429 25 x 25 1,50 to 2,00 M8 15,00 25,70 6,80 19,00 / 23,00 29,40
00300400435 25 x 25 1,50 M8 4,50 25,70 6,80 19,00 / 23,00 29,40
00300400320 25 x 25 1,50 to 2,00 M10 5,00 26,00 6,50 18,50 / 23,30 12,80
00300400430 25 x 25 1,50 to 2,00 M10 15,00 25,00 6,80 19,00 / 23,00 29,40
00300400436 25 x 25 1,50 M10 5,00 25,00 6,80 19,00 / 23,00 29,40
00300400323 30 x 30 1,50 to 2,00 M8 5,00 29,80 8,00 23,00 / 27,00 12,80
00300400431 30 x 30 1,50 to 2,00 M8 15,00 30,00 7,60 24,00 / 28,00 30,00
00300400324 30 x 30 1,50 to 2,00 M10 4,00 29,80 8,00 24,00 / 28,30 12,80
00300400432 30 x 30 1,50 to 2,00 M10 15,00 30,00 7,60 24,00 / 28,00 30,00
00300400437 30 x 30 1,50 M10 5,00 30,00 7,70 24,00 / 28,00 30,00
00300410007 30 x 30 1,50 to 2,00 M10 15,00 30,00 7,60 24,00 / 28,00 30,00
00300400326 30 x 30 2,50 M10 5,00 29,80 8,00 23,00 / 26,80 13,00
00300400327 35 x 35 1,50 to 2,00 M10 5,00 34,80 8,00 29,30 / 33,80 13,20
00300400328 40 x 40 1,50 to 2,00 M10 5,00 39,60 8,00 33,70 / 38,20 13,20
00300401047 45 x 45 1,50 to 2,00 M10 5,00 44,70 8,00 39,20 / 42,50 13,40
02300400999 80 x 80 2,00 M12 10,00 80,00 5,00 74,00 / 76,00 30,00
02300401000 80 x 80 3,00 M10 8,00 80,00 5,00 72,00 / 74,00 30,00

If you are interested in our family LJ, you may be interested in these families as well:

Rotatory wheel with brake made of polypropylene. Its threaded stud makes it ideal to be placed in threaded inserts. The recommended individual loading capacity is 50 kilos.   Our adjustable foot has a knurled base for easier handling.   Our adjustable foot with a hexagonal screw for easier fitting.
