Our ribbed insert for square tubes has been designed in 2 parts with an hexagon nut included in the set. It is also available for rectangular tubes: LJVZ. It is suitable for our adjustable feet.
  RAL colors manufactured

Drawing PDF:
UL94:
IP:
RoHS:
Measures expressed in: Millimeters
Video:

LJV
LJV

Reference
For Tube (D)
Tube Thickness
Metric Thread
H
L



More
Info.
02300400951 18 x 18 1,00 to 1,50 M8 5,00 32,00
02300400952 20 x 20 1,50 to 2,00 M6 5,00 34,00
02300400953 20 x 20 1,50 to 2,00 M8 5,00 34,00
02300400954 20 x 20 1,50 to 2,00 M10 10,00 33,00
02300400955 20 x 20 2,00 M8 5,00 34,00
00300400348 22 x 22 1,50 to 2,00 M8 5,00 34,00
02300400958 25 x 25 1,00 to 1,50 M8 5,00 34,00
02300400959 25 x 25 1,50 M10 5,00 33,00
02300400962 25 x 25 2,00 M8 5,00 34,00
02300400963 25 x 25 2,00 M10 5,00 34,00
02300400964 25 x 25 3,00 M10 5,00 33,00
02300400965 30 x 30 1,00 to 1,50 M10 5,00 34,00
02300400966 30 x 30 1,50 to 2,00 M8 5,00 32,50
02300400967 30 x 30 1,50 to 2,00 M10 5,00 34,00
02300400968 30 x 30 2,00 M10 5,00 34,00
02300400969 30 x 30 2,50 M10 5,00 33,00
02300400970 30 x 30 2,50 M10 5,00 33,00
02300400971 32 x 32 2,00 M10 5,00 33,00
02300400972 35 x 35 1,00 to 2,00 M10 5,00 34,00
02300400974 35 x 35 1,50 to 2,00 M8 5,00 34,00
02300400973 35 x 35 1,50 M12 5,00 34,00
02300400975 35 x 35 1,50 to 2,00 M12 5,00 34,00
02300800020 35 x 35 2,00 M10 5,00 33,00
02300800023 37,5 x 37,5 1,50 M10 5,00 36,60
02300400981 40 x 40 1,20 to 1,50 M10 5,00 33,00
02300400979 40 x 40 1,50 to 2,00 M8 5,00 33,00
02300400980 40 x 40 1,50 to 2,00 M10 5,00 25,00
02300400982 40 x 40 1,50 to 2,00 M10 5,00 33,00
02300400983 40 x 40 1,50 to 2,00 M12 5,00 33,00
02300400984 40 x 40 1,50 to 2,00 M16 5,00 33,00
02300401005 40 x 40 2,00 M8 5,00 32,00
02300400986 40 x 40 3,00 M10 5,00 31,00
02300400988 45 x 45 1,50 to 2,00 M8 5,00 34,00
02300400989 50 x 50 1,50 M10 5,00 34,00
02300400990 50 x 50 2,00 M8 5,00 34,00
00300401064 50 x 50 2,00 M10 5,00 32,00
02300400992 50 x 50 2,50 M10 5,00 33,00
02300400993 50 x 50 3,00 M10 5,00 34,00
02300400994 50 x 50 3,00 M12 5,00 34,00
02300400995 55 x 55 2,00 M10 5,00 34,00
00300400349 60 x 60 1,50 to 2,00 M10 5,00 34,00
02300400996 60 x 60 1,50 to 2,00 M10 5,00 34,00
00300400350 60 x 60 1,50 to 2,00 M12 5,00 34,00

If you are interested in our family LJV, you may be interested in these families as well:

Rotatory wheel with brake made of polypropylene. Its threaded stud makes it ideal to be placed in threaded inserts. The recommended individual loading capacity is 50 kilos.   <p>Our <b>LHVFB levelling feet</b> with round base are manufactured in <b>Polyamide 6 (PA6)</b> and include a nut integrated into the body for height adjustment using an adjustable wrench. The thread is manufactured in <b>Zinc-Plated Steel (ZCS)</b>.</p> <p>Available with different base configurations depending on the reference: Type 1 with hollow base, Type 2 with flat base, Type 3 with concentric braking grooves, and Type 4 with cross recess for easier levelling.</p> <p>· <b>Material:</b> PA6 with Zinc-Plated Steel (ZCS) thread<br> · <b>Available finishes:</b> Polished/gloss or textured/matte<br> · <b>Options:</b> Stainless Steel (SS) version and Allen socket</p> <p><i>Static axial load capacity varies depending on the reference. For further information and special configurations, please contact our sales department.</i></p><i>*Polished/bright or eroded/matte finish.</i><br> <i>*Supplied with Allen housing at the thread end.</i><br> <i>*Manufactured in Stainless Steel (SS).</i><br><br> For more details, contact our sales department.<br>   Our adjustable foot has a knurled base for easier handling.   Our female wing knob is also available as a male wing knob, please visit our family LHMB.   Our hinge 3-way connector has been designed for square tubes. It has an angle which goes from 0º to 190º, or from 45º to 200º, depending on the reference.
