Our nylon shoulder screws provide excellent resistance against chemicals (see table of properties). It is a material with a high level of dielectric strength, it does not rust and prevents damage due to breaking strength during mechanical stress.
  RAL colors manufactured

  Possible to get dyed colors

Drawing PDF:
UL94:   V2
IP:
RoHS:
Measures expressed in: Millimeters
Video:

MWZ
MWZ

Reference
Thread
D
L
A
H
J
T
E



More
Info.
00100402608 10 · 24 6,17 6,35 9,30 4,62 3,25 2,39 9,14
00100402609 10 · 24 6,17 9,53 9,30 4,62 3,25 2,39 9,14
00100402610 10 · 24 6,17 12,70 9,30 4,62 3,25 2,39 9,14
00100402611 10 · 24 6,17 15,88 9,30 4,62 3,25 2,39 9,14
00100402612 10 · 24 6,17 19,05 9,30 4,62 3,25 2,39 9,14
00100402613 10 · 24 6,17 25,40 9,30 4,62 3,25 2,39 9,14
00100402614 10 · 24 6,17 31,75 9,30 4,62 3,25 2,39 9,14
00100402615 10 · 24 6,17 38,10 9,30 4,62 3,25 2,39 9,14
00100402616 10 · 24 6,17 44,45 9,30 4,62 3,25 2,39 9,14
00100402617 10 · 24 6,17 50,80 9,30 4,62 3,25 2,39 9,14
00100402618 10 · 24 6,17 57,15 9,30 4,62 3,25 2,39 9,14
00100402619 1/4 · 20 7,77 6,35 10,90 5,44 4,04 2,97 10,74
00100402620 1/4 · 20 7,77 7,92 10,90 5,44 4,04 2,97 10,74
00100402621 1/4 · 20 7,77 9,53 10,90 5,44 4,04 2,97 10,74
00100402622 1/4 · 20 7,77 12,70 10,90 5,44 4,04 2,97 10,74
00100402623 1/4 · 20 7,77 15,88 10,90 5,44 4,04 2,97 10,74
00100402624 1/4 · 20 7,77 19,05 10,90 5,44 4,04 2,97 10,74
00100402625 1/4 · 20 7,77 25,40 10,90 5,44 4,04 2,97 10,74
00100402626 1/4 · 20 7,77 38,10 10,90 5,44 4,04 2,97 10,74
00100402627 1/4 · 20 7,77 44,45 10,90 5,44 4,04 2,97 10,74
00100402628 1/4 · 20 7,77 50,80 10,90 5,44 4,04 2,97 10,74
00100402629 5/16 · 18 9,35 6,35 14,05 6,22 4,85 3,58 12,45
00100402630 5/16 · 18 9,35 9,53 14,05 6,22 4,85 3,58 12,45
00100402631 5/16 · 18 9,35 12,70 14,05 6,22 4,85 3,58 12,45
00100402632 5/16 · 18 9,35 15,88 14,05 6,22 4,85 3,58 12,45
00100402633 5/16 · 18 9,35 19,05 14,05 6,22 4,85 3,58 12,45
00100402634 5/16 · 18 9,35 25,40 14,05 6,22 4,85 3,58 12,45
00100402635 5/16 · 18 9,35 31,75 14,05 6,22 4,85 3,58 12,45
00100402636 5/16 · 18 9,35 38,10 14,05 6,22 4,85 3,58 12,45
00100402637 5/16 · 18 9,35 44,45 14,05 6,22 4,85 3,58 12,45
00100402638 5/16 · 18 9,35 50,80 14,05 6,22 4,85 3,58 12,45
00100402639 5/16 · 18 9,35 57,15 14,05 6,22 4,85 3,58 12,45
00100402640 3/8 · 16 12,52 9,53 18,80 7,80 6,43 4,78 15,49
00100402641 3/8 · 16 12,52 12,70 18,80 7,80 6,43 4,78 15,49
00100402642 3/8 · 16 12,52 15,88 18,80 7,80 6,43 4,78 15,49
00100402643 3/8 · 16 12,52 19,05 18,80 7,80 6,43 4,78 15,49
00100402644 3/8 · 16 12,52 25,40 18,80 7,80 6,43 4,78 15,49
00100402645 3/8 · 16 12,52 31,75 18,80 7,80 6,43 4,78 15,49
00100402646 3/8 · 16 12,52 38,10 18,80 7,80 6,43 4,78 15,49
00100402647 3/8 · 16 12,52 44,45 18,80 7,80 6,43 4,78 15,49
00100402648 3/8 · 16 12,52 50,80 18,80 7,80 6,43 4,78 15,49
