Part numbers and dimensions of Semi-blind grommet
| Reference | Hole size (A) |
Panel thickness (B) |
C |
F |
D |
E |
More Info. |
||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 01012000215 | 19,60 | 2,00 | 15,50 | 2,10 | 3,90 | 23,90 | |||||||
| 01012000217 | 26,00 | 2,40 | 20,80 | 2,40 | 3,80 | 30,00 |
