Part numbers and dimensions of Round head knob
| Reference | Suitable for |
A |
B |
C |
More Info. |
||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 00100101000 | M3 | 9,53 | 5,16 | 8,33 | |||||||||
| 00100101005 | M4 | 12,70 | 5,56 | 9,53 | |||||||||
| 00100101011 | M5 | 16,60 | 6,35 | 10,72 | |||||||||
| 00100100999 | M6 | 19,05 | 7,93 | 12,70 | |||||||||
| 00100101017 | M6 | 25,40 | 8,33 | 12,70 | |||||||||
| 00100101028 | M8 | 25,80 | 10,15 | 15,20 |
