Our hexagon shaped lock nut with round sealing flange has been designed to fit a variety of thread sizes, and to execute a big range of applications and to be used together with a cable gland. Nylon nuts are durable, non-conductive and resistant to corrosion.

Drawing PDF:
UL94:   V0
IP:
RoHS:
Measures expressed in: Millimeters


Reference
Metric Thread
A
B



More
Info.
01500800048 M16 7,00 19,00
01500800049 M20 8,00 24,00
01500800050 M25 9,00 27,00

If you are interested in our family PRTU, you may be interested in these families as well:

This part is a 100% waterproof cable gland (IP68 - 5 bar). Its design gives the possibility to fit several cable diameters with secure protection and fastening. It can be supplied with a plug protector, and an O-ring PRP for watertightness and an adapter joint PRTI for several cables. Also, you can find the corresponding lock nut: PRTUE. Please contact us for more information.   Our cable gland has been designed for cables, that once they are fitted may have certain mobility, preventing damage. You can find the correspondig lock nut, please visit our family: PRTUE.   This o-ring is ideal to get a good and water-proof sealing in our cable glands PRPRE and our plugs PRTH and PRT. It can be used in the majority of industrial applications including water, oil, petrol and most chemicals. Our o-ring is available for metric thread and for PG thread.   Our hexagon shaped lock nut has been designed to fit a variety of thread sizes, and to execute a big range of applications and to be used together with a cable gland. Nylon nuts are durable, non-conductive and resistant to corrosion.   Our hexagon shaped lock nut <b>manufactured in brass</b>, has been designed to fit a variety of thread sizes, and to execute a big range of applications and to be used together with a cable gland.
