Double ended clip that permits two panels to be connected in an easy and secure way, from the center. No fastener head will be visable. This clip is simple and quick to install under fingertip pressure.

Drawing PDF:
UL94:
IP:
RoHS:
Measures expressed in: Millimeters


Reference
Hole size
A
Panel thickness
A

A

B
Hole size
C
Panel Thickness
C

C

D



More
Info.
50003000002 4,00 2,60 to 6,30 7,80 1,75 4,00 2,60 to 6,30 7,80 7,50
01000000003 6,35 0,50 to 6,90 11,10 2,79 6,35 0,50 to 6,90 11,10 8,20
50003000001 7,50 3,00 to 8,00 17,50 1,00 7,50 3,00 to 8,00 17,50 19,00
01000000004 7,93 to 8,33 2,40 to 7,60 8,76 1,00 7,93 to 8,33 2,40 to 7,60 8,76 12,80
01000000001 7,93 to 8,33 3,20 to 9,50 21,88 1,10 7,93 to 8,33 3,50 to 19,00 11,25 12,70

If you are interested in our family HDEPR, you may be interested in these families as well:

Double ended clip that permits two panels to be connected in an easy and secure way, from the center. No fastener head will be visable. This clip is simple and quick to install under fingertip pressure.   Double ended pine tree clip  that permits two panels to be connected in an easy and secure way, from the center. No fastener head will be visable. This clip is simple and quick to install under fingertip pressure.   This rivet - Christmas tree type clip offers a very good fastening system and assures a good finishing. Its offers an easy hand installation. This part is ideal for applications where there is a soft material (like textile) and a more rigid material. This Christmas tree type clip can be used in blind hole applications.This rivet-clip is molded in corrosion, abrasion, and vibration resistant nylon.   Double ended clip that permits two panels to be connected in an easy and secure way, from the center. No fastener head will be visable. This clip is simple and quick to install under fingertip pressure.
