Our barbed Y connectors resist working pressures up to 125 PSI, without clamps or ties. Every barb on our parts is manufactured without a parting line on the sealing surface of the barb to ensure a leak-proof seal every time.

Material: PC - PA66 - PP - PVDF
Standard colors: Transparent - Natural - White
UL94:   V2
IP:
RoHS:
Measures expressed in: Millimeters
Drawing PDF:


Reference
D
C
A
B
L

PDF
3D IGS
Add
00500501158 1,73 2,36 1,19 4,78 12,95
00500501162 2,41 3,56 1,52 7,95 20,83
00500501166 3,18 4,70 2,03 9,60 23,62
00500501170 3,91 6,15 2,54 10,03 33,34
00500501174 4,75 6,65 3,05 10,54 34,13
00500501178 6,35 8,89 4,78 11,35 43,66
00500502038 6,35 8,89 4,78 11,35 45,24
00500502039 6,35 8,89 4,78 11,35 44,45
00500501182 9,53 11,81 6,35 15,75 48,42
